A Guide to Different Blockchain Philosophies: UTXO vs. Account-Based Models

A UTXO is an output of a previous transaction that has not yet been spent and can be used as an input for a new transaction. The entire state of the Bitcoin network is not a list of account balances, but rather a global set of all available UTXOs at any given moment.

A standard Bitcoin transaction consists of two primary components:

1. Inputs: A list of references to existing UTXOs that the sender owns. To spend a UTXO, the sender must provide a digital signature proving ownership, which is validated against a locking script that was placed on that UTXO when it was created. This is the "unlocking" process.

2. Outputs: A list of new UTXOs being created by this transaction. Each output contains a value (an amount of BTC) and a new locking script (scriptPubKey) that defines the conditions required to spend it in the future.

Let's illustrate with an example.

Alice wants to send 1 BTC to Bob. Alice doesn't have a single UTXO of exactly 1 BTC. Instead, her wallet controls two UTXOs: one worth 0.7 BTC and another worth 0.6 BTC.

Her transaction would look like this:

Inputs:

• Reference to her 0.7 BTC UTXO (and a signature to unlock it).

• Reference to her 0.6 BTC UTXO (and a signature to unlock it).

• Total Input Value: 1.3 BTC

Outputs:

• A new UTXO of 1.0 BTC with a locking script that specifies Bob's public key (this is the payment to Bob).

• A new UTXO of 0.2999 BTC with a locking script specifying Alice's own public key. This is her change.

• Total Output Value: 1.2999 BTC

The small difference between the total input and total output (0.0001 BTC) is the transaction fee, which is implicitly claimed by the miner who includes the transaction in a block.

The locking and unlocking scripts are written in a simple, stack-based language called Bitcoin Script. Crucially, Bitcoin Script is not Turing-complete. This was an intentional design choice to prioritize security and predictability. It has no loops and a limited set of operations, which drastically reduces the attack surface and makes it possible to analyze the outcome of a script with certainty.

While it cannot be used for the kind of complex dApps seen on Ethereum, it is powerful enough for various functionalities, including:

• P2PKH (Pay-to-Public-Key-Hash): The standard transaction type described above.

• Multi-signature Scripts: Requiring M-of-N signatures to spend a UTXO (e.g., 2 out of 3 company directors must sign).

• Timelocks (CheckLockTimeVerify/CheckSequenceVerify): Making a UTXO unspendable until a certain time or block height has passed.

Pros:

• Scalability & Parallel Processing: Since transactions only need to reference specific UTXOs, those that don't share inputs can be validated in parallel. This allows for a higher degree of processing efficiency by nodes.

• Enhanced Privacy: By default, each transaction input comes from a different address, and the change goes to a new, unused address. This makes it harder to link transactions to a single real-world identity if users practice good wallet hygiene (i.e., not reusing addresses). Techniques like CoinJoin can leverage this structure to further obfuscate the transaction graph.

Cons:

• Complex Smart Contracts: The stateless nature of UTXOs makes it difficult to build applications that require a shared state that evolves over time (e.g., a decentralized exchange or a lending protocol). The logic must be embedded in each transaction, and the state must be carried forward from one UTXO to the next, which is cumbersome.

• State Bloat ("UTXO Dust"): The set of all UTXOs must be maintained in the memory of full nodes for quick validation. The creation of tiny, economically unspendable UTXOs (known as "dust") can bloat this set, increasing the hardware requirements for running a node.

The state of Ethereum is a massive data structure called the World State, which maps account addresses to their corresponding account states. This is physically stored in a highly efficient data structure known as a Merkle Patricia Trie.

There are two types of accounts in Ethereum:

1. Externally Owned Accounts (EOAs): These are the accounts controlled by users via their private keys. An EOA's state consists of two fields:

   • nonce: A counter that indicates the number of transactions sent from this account. It's a critical security feature that prevents replay attacks.

   • balance: The account's balance in Ether.

2. Contract Accounts: These accounts are controlled by their embedded code. In addition to a nonce and balance, they have two more fields:

   • codeHash: The hash of the smart contract code stored on the blockchain. This code is immutable.

   • storageRoot: The hash of the root of another Merkle Patricia Trie, this one dedicated to storing the contract's specific data (its internal state).

When you send ETH from one EOA to another, the blockchain simply decrements the sender's balance and increments the receiver's. When you interact with a smart contract, you send a transaction that triggers a function within its code. This function can read/write to the contract's storage, send ETH, or even call other contracts, leading to complex and potentially cascading changes across the World State.

The heart of Ethereum's programmability is the Ethereum Virtual Machine (EVM). The EVM is a quasi-Turing-complete, sandboxed execution environment for smart contracts. "Quasi" because all operations are metered by a mechanism called gas.

Gas is the unit used to measure the computational cost of an operation. Simple operations like addition cost very little gas, while complex operations like writing to storage (SSTORE) are very expensive. When a user sends a transaction, they specify a gasLimit (the maximum amount of gas they are willing to consume) and a fee structure. Under the EIP-1559 standard, this includes:

• maxPriorityFeePerGas: A "tip" to the validator to incentivize inclusion.

• maxFeePerGas: The absolute maximum the user is willing to pay per unit of gas.

The actual fee is the gasUsed multiplied by (baseFee + priorityFee), where the baseFee is algorithmically determined by network congestion and is burned, while the priorityFee goes to the validator. This mechanism prevents infinite loops (a transaction runs out of gas and reverts) and allows the network to manage block space demand dynamically.

Pros:

• Rich dApp Ecosystem: The Turing-complete nature of the EVM and the ease of managing a shared state have made it the de facto standard for decentralized finance (DeFi), NFTs, and other complex applications.

• Developer Intuitiveness: The model is more familiar to developers coming from traditional programming backgrounds, as it resembles object-oriented programming where objects (contracts) have their own internal state.

Cons:

• Sequential Processing: Because any transaction could potentially interact with any account, they must generally be processed sequentially within a block. One complex transaction from a popular dApp can hold up other, unrelated transactions, leading to network congestion. This is a significant scalability bottleneck.

• Replay Attack Risk: The nonce is essential. Without it, a malicious actor could copy a signed transaction (e.g., "send 1 ETH to Bob") and rebroadcast it over and over, draining the sender's account.

So, how does Rango technically handle a swap from Bitcoin (UTXO) to USDC on Arbitrum (Account-based)? The user simply specifies the input and output, and Rango's backend takes care of the complex routing, which may involve one of several mechanisms:

1. Native Asset Swaps (via THORChain, Maya Protocol, etc.): Rango integrates with protocols that allow for swaps of native assets without wrapping. For a Bitcoin swap, the process looks like this:

   • Rango's API instructs the user's wallet to construct a Bitcoin transaction.

   • This transaction sends the BTC to a specific vault address controlled by the THORChain or Maya network.

   • Crucially, the transaction includes an OP_RETURN output, which contains a "memo" with instructions: the target asset (e.g., USDC), the destination chain (Arbitrum), and the user's Arbitrum address.

   • The decentralized network of nodes reads this memo, and its liquidity pools execute the swap internally, sending the final USDC amount to the user on the Arbitrum network.

2. Wrapped Assets (e.g., Wrapped BTC): For other routes, Rango may utilize wrapped assets.

   • The user's native Bitcoin is sent to a custodian (which can be a centralized entity or a decentralized multi-sig contract).

   • The custodian locks the Bitcoin and mints an equivalent amount of an ERC-20 token, such as WBTC (Wrapped Bitcoin), on an EVM chain like Ethereum.

   • Rango can then route this WBTC through an integrated DEX on Ethereum (like Uniswap) to swap it for USDC.

   • Finally, Rango will use a bridge (like Stargate or Across) to move the USDC from Ethereum to the user's address on Arbitrum.

The beauty of Rango lies in its abstraction layer. A developer building a dApp that needs to accept payments from any chain can integrate the Rango SDK. They don't need to worry about the underlying architecture of each chain.

When a user wants to perform a swap, the Rango API provides the dApp with the correct transaction type:

• For a Bitcoin transaction, it will provide a PSBT (Partially Signed Bitcoin Transaction), which the wallet signs and broadcasts.

• For an EVM transaction, it will provide the necessary transaction data (to, value, data), which the wallet signs using eth_sendRawTransaction.

• For Solana, it will provide a transaction object formatted for the Solana runtime.

This powerful abstraction turns a complex, multi-step, multi-chain journey into a single, seamless user experience. Rango's routing engine automatically chooses the best path, be it via native swaps, wrapping, or a complex chain of DEXs and bridges, based on factors like final output amount, transaction speed, and fees.
