Uniswap V3: The Mathematical and Economic Powerhouse of Modern AMMs

At its core, Uniswap V3 retains the constant product invariant (i.e. x·y=k) but localises it: liquidity is only “active” over sub-ranges of the full price domain. Key primitives:

• Price expressed via √P (square root of price) for mathematical convenience.

• Ticks: Discrete price intervals (granularity depends on tick spacing per fee tier). LPs choose lower and upper tick bounds defining their active range.

• Liquidity (L) associated with a position over [P_min, P_max]. Only when current price P ∈ (P_min, P_max) is the LP “in-range” and earning fees, holding a mix of both tokens as per formulas. Outside that range, all of the LP’s value is in one token (depending on whether price is above or below bound).

Because liquidity is segmented, Uniswap V3 defines virtual reserves for each active range (or “segment”) so that within any segment, the behaviour is analogous to Uniswap V2’s x·y=k, but scaled by L.

If we denote:

• P: current price (token1 per token0),

• P_min, P_max: the lower and upper bounds of an LP’s range,

• √ P, √ P_min, √ P_max: their square roots,

then:

• The amount of token0 the LP must deposit (when P is between the bounds) is: amount0 = L . ( √ P_max - √ P) / (√ P . √ P_max )

• The amount of token1 is: amount1 = L . (√ P - √ P_min)



These come from integrating the constant product curve over the interval, normalizing by √P etc.

When P ≤ P_min: the LP’s position holds only token0.

When P ≥ P_max: only token1.

It is also common to see formulas for L in terms of desired amounts of tokens if you fix range bounds and current price. For example, if you wish to deposit only token0 in range [P, P_max] (i.e. a one-sided liquidity above current price), a formula arises by solving backwards from the amount0 expression.

Implementation details are critical to precision and performance:

• Q Notation (e.g. sqrtPriceX96): this denotes fixed-point numbers. For example, sqrtPriceX96 = √P × 2^96, stored as an integer. This avoids floating point in EVM, preserves precision, and allows exact arithmetic in many parts of the code. Uniswap’s math uses these heavily.

• Ticks and Tick Spacing: Not every tick is valid for every pool. Fee tiers are associated with tick spacings (larger spacing = coarser granularity). Tick bounds for LP positions must align with these spacings. As price moves, it passes through ticks; when crossing a tick at which liquidity starts or ends, the active liquidity L changes.

Swaps in V3 proceed similarly to V2 when within a single active range (i.e. between adjacent ticks). But when a swap’s price movement crosses tick boundaries, one must adjust the liquidity L as some LP positions become inactive or active, which affects the invariant for subsequent segments.

From a slippage perspective: for a given amount in, price impact depends on available in-range liquidity. Because liquidity may be highly concentrated around the current price, slippage can be far lower than in V2 for well-funded pools. But large trades that fall outside core concentrated zones may traverse many ticks, incurring stepwise liquidity changes and thus price jumps / slippage and increased gas.

Because LPs can select tight ranges, IL can be more acute than in V2 when price moves beyond the bounds: when price leaves the LP’s range, the LP’s position becomes 100% one token. That token may then lose value relative to holding both tokens or relative to a benchmark like “just holding them both (HODL)”.

Recent empirical studies show that over many pools, total fees earned vs total IL suffered can vary. In some cases LPs in V3 have earned substantially more fees, enough to offset larger IL; in some other settings, narrow strategies without rebalancing do worse than a simple deposit + HODL or a V2-style strategy.

Mathematically, IL can be derived similarly to V2’s formula but restricted to the range; the loss relative to HODLing depends on price movement and how long the LP remained in-range. Strategic rebalancing (changing the tick bounds) can mitigate this loss but incurs gas/trading costs.

After Uniswap V3’s code license expired (initial Business Source License period ended), many protocols on other chains forked/replicated the V3 model. Examples:

• PancakeSwap V3 on BNB Chain: introduced after the license expiry; adopted multiple fee tiers tuned to BSC’s user base, including ultra-low tiers (e.g. 0.01%) for stable swaps. Also built UX improvements like Position Manager tools and aim to reduce friction for users selecting ranges.

• QuickSwap V3 (Polygon), Sushi Trident concentrated pool features, etc. These cross-chain deployments generally preserve the math and core architecture, but make chain-specific optimizations (gas, UI, integration with chain’s token standards, etc.).

Because V3 positions are non-fungible and range selection is nontrivial, several protocols provide vaults or strategy managers:

• Arrakis Finance (formerly G-UNI by Gelato) provides vaults that hold V3 positions, automating range selection, rebalancing, fee reinvestment, and exposing a fungible token to end users. In particular, Arrakis vaults permit LPs to benefit from narrow-range positioning without manually managing ticks. MakerDAO, for example, uses an Arrakis vault for USDC/DAI to earn fees on reserves, dramatically increasing yield vs passive holdings.

• Gamma Strategies, Visor, Charm, etc.: active managers who monitor volatility, volume, price drift to optimise when to adjust ranges. Some use machine learning or neural network based strategies to decide when to contract or expand ranges (or move them) to maximize net returns (fees earned minus gas / reposition cost / IL).

Beyond straight forks or vaults, other protocols have adapted or built upon the V3 concentrated liquidity concept:

• Trader Joe’s Liquidity Book on Avalanche: inspired by V3 (ticks / bins) but uses discrete “bins” with uniform pricing within each bin, and dynamic fees that increase during rapid price move or slippage (when traversing many bins). It also emphasises UX improvements and risk control for LPs.

• Dynamic Fees / Volatility-Aware Adjustments: Some platforms or strategies add mechanisms to adjust fees or widen ranges dynamically depending on volatility, slippage risk, or external signals. This helps in balancing LP risk and trader cost.

A few key results from academic or protocol-level research:

• Impermanent Loss vs Fee Revenue: In many large V3 pools (especially volatile token pairs), aggregate IL has exceeded fees for some LPs who did not manage ranges actively. Empirical studies show that in some pools, total fees earned since inception were less than cumulative IL, meaning a simple HODL would have yielded more.

• Optimal Strategies Depend on Environment: (“Strategic Liquidity Provision in Uniswap V3”): optimal LP behavior varies depending on volatility, frequency of price movements, trading volume, and gas costs. Tight ranges yield higher returns when price stays inside range; but if price drifts often, wide or multi-range strategies or frequent rebalancing become valuable.

• Liquidity Surface / Time-Tick Dynamics: newer work (e.g. “Dynamics of Liquidity Surfaces in Uniswap v3”) models how liquidity distribution over ticks (i.e. across price ranges) evolves over time. Factors include drift toward the current price, clustering of liquidity in low-tick-distance ranges, and how LPs reposition. Such surfaces show few dominant eigenfunctions in tick-space explaining most variation, suggesting simplified strategies may capture much of the benefit.
